高速电机轴承
高速电机轴承,6200系列深沟球轴承,轴承型号查询表
公制 >>6200系列深沟球轴承，适用所有密封结构
|
轴承 型号 |
主要尺寸 | 推荐安装尺寸 | ||||||||||||
| d | D | B,C |
r (最小)
|
da (最小)
|
da (最大)
|
Da (最大)
|
||||||||
| mm | inch | mm | inch | mm | inch | mm | inch | mm | inch | mm | inch | mm | inch | |
| 624 | 4 | 0.1575 | 13 | 0.5118 | 5 | 0.1968 | 0.2 | 0.007 | 5.6 | 0.220 | 6.2 | 0.244 | 11.4 | 0.449 |
| 625 | 5 | 0.1969 | 13 | 0.6299 | 5 | 0.1968 | 0.3 | 0.012 | 7.0 | 0.276 | 7.6 | 0.299 | 14.0 | 0.551 |
| 626 | 6 | 0.2362 | 16 | 0.7480 | 6 | 0.2362 | 0.3 | 0.012 | 8.0 | 0.315 | 9.5 | 0.374 | 17.0 | 0.669 |
| 627 | 7 | 0.2756 | 22 | 0.8661 | 7 | 0.2756 | 0.3 | 0.012 | 9.0 | 0.354 | 12.2 | 0.480 | 20.0 | 0.787 |
| 628 | 5 | 0.3149 | 24 | 0.9448 | 8 | 0.3149 | 0.3 | 0.012 | 10.0 | 0.394 | 12.1 | 0.476 | 17.0 | 0.669 |
| 629 | 9 | 0.3543 | 26 | 1.0236 | 8 | 0.3149 | 0.3 | 0.012 | 11.5 | 0.453 | ... | ... | 14.0 | 0.945 |
| 6200 | 10 | 0.3937 | 30 | 1.1811 | 9 | 0.3543 | 0.6 | 0.024 | 12.7 | 0.500 | 16.0 | 0.630 | 26.0 | 1.024 |
| 6201 | 12 | 0.4724 | 32 | 1.2598 | 10 | 0.3937 | 0.6 | 0.024 | 14.7 | 0.578 | 17.0 | 0.670 | 28.0 | 1.102 |
| 6201/2 | 12.7 | 0.5000 | 32 | 1.2598 | 10 | 0.3937 | 0.6 | 0.024 | 15.1 | 0.595 | 17.0 | 0.670 | 27.0 | 1.063 |
| 6202 | 15 | 0.5906 | 35 | 1.3780 | 11 | 0.4331 | 0.6 | 0.024 | 17.9 | 0.703 | 20.0 | 0.787 | 31.0 | 1.220 |
| 6202-5 | 15.875 | 0.6250 | 35 | 1.3780 | 11 | 0.4331 | 0.6 | 0.024 | 18.5 | 0.730 | 19.0 | 0.749 | 30.0 | 1.181 |
| 6202-6 | 16 | 0.6299 | 35 | 1.3780 | 11 | 0.4331 | 0.6 | 0.024 | 18.8 | 0.740 | 19.0 | 0.749 | 30.0 | 1.181 |
| 6203 | 17 | 0.6693 | 40 | 1.5748 | 12 | 0.4724 | 0.6 | 0.024 | 20.0 | 0.787 | 23.5 | 0.926 | 36.0 | 1.417 |
| 6203/8 | 15.875 | 0.6250 | 40 | 1.5748 | 12 | 0.4724 | 0.6 | 0.024 | 19.1 | 0.750 | 23.5 | 0.926 | 35.1 | 1.380 |
| 6204 | 20 | 0.7874 | 47 | 1.8504 | 14 | 0.5512 | 1.0 | 0.039 | 24.6 | 0.969 | 28.0 | 1.102 | 42.0 | 1.654 |
| 6205 | 25 | 0.9843 | 52 | 2.0470 | 15 | 0.5906 | 1.0 | 0.039 | 30.0 | 1.181 | 32.0 | 1.260 | 47.0 | 1.850 |
| 6206 | 30 | 1.1811 | 62 | 2.4409 | 16 | 0.6299 | 1.0 | 0.039 | 35.0 | 1.378 | 39.0 | 1.535 | 57.0 | 2.244 |
| 6207 | 35 | 1.3780 | 72 | 2.8346 | 17 | 0.6693 | 1.1 | 0.043 | 41.0 | 1.614 | 45.0 | 1.772 | 65.5 | 2.579 |
| 6208 | 40 | 1.5748 | 80 | 3.1496 | 18 | 0.7087 | 1.1 | 0.043 | 46.0 | 1.811 | 51.0 | 2.008 | 73.5 | 2.894 |
| 6209 | 45 | 1.7717 | 85 | 3.3465 | 19 | 0.7480 | 1.1 | 0.043 | 51.0 | 2.008 | 55.5 | 2.185 | 78.5 | 3.091 |
| 6210 | 50 | 1.9685 | 90 | 3.5433 | 20 | 0.7874 | 1.1 | 0.043 | 56.0 | 2.205 | 60.0 | 2.362 | 83.5 | 3.287 |
| 6211 | 55 | 2.1654 | 100 | 3.9370 | 21 | 0.8268 | 1.5 | 0.059 | 62.0 | 2.441 | 67.0 | 2.638 | 92.0 | 3.622 |
| 6212 | 60 | 2.3622 | 110 | 4.3307 | 22 | 0.8661 | 1.5 | 0.059 | 68.0 | 2.677 | 75.0 | 2.953 | 102.0 | 4.016 |
| 6213 | 65 | 2.5591 | 120 | 4.7244 | 23 | 0.9055 | 1.5 | 0.059 | 73.0 | 2.874 | 80.5 | 3.169 | 112.0 | 4.409 |
| 6214 | 70 | 2.7559 | 125 | 4.9213 | 24 | 0.9449 | 1.5 | 0.059 | 78.0 | 3.071 | 85.0 | 3.346 | 117.0 | 4.606 |
| 6215 | 75 | 2.9528 | 130 | 5.1181 | 25 | 0.9843 | 1.5 | 0.059 | 83.0 | 3.268 | 90.5 | 3.563 | 122.0 | 4.803 |
| 6216 | 80 | 3.1496 | 140 | 5.5118 | 26 | 1.0236 | 2.0 | 0.0787 | 89.0 | 3.504 | 95.5 | 3.760 | 131.0 | 5.157 |
| 6217 | 85 | 3.3465 | 150 | 5.9055 | 28 | 1.1024 | 2.0 | 0.0787 | 94.0 | 3.701 | 103.0 | 4.055 | 141.0 | 5.551 |
| 6218 | 90 | 3.5433 | 160 | 6.2992 | 30 | 1.1811 | 2.0 | 0.0787 | 99.0 | 3.898 | 109.0 | 4.291 | 151.0 | 5.945 |
| 6219 | 95 | 3.7402 | 170 | 6.6929 | 32 | 1.2598 | 2.1 | 0.0827 | 106.0 | 4.173 | 116.0 | 4.567 | 159.0 | 6.260 |
| 6220 | 100 | 3.9370 | 180 | 7.0866 | 34 | 1.3386 | 2.1 | 0.0827 | 111.0 | 4.370 | 122.0 | 4.803 | 169.0 | 6.654 |
| 6221 | 105 | 4.1399 | 190 | 7.4803 | 36 | 1.4173 | 2.1 | 0.0827 | 116.0 | 4.567 | 125.0 | 4.921 | 179.0 | 7.047 |
| 6222 | 110 | 4.3307 | 200 | 7.8740 | 38 | 1.4961 | 2.1 | 0.0827 | 121.0 | 4.764 | 132.0 | 5.197 | 189.0 | 7.441 |
☆卡锐轴承保留修改表中技术规则和其它数据的权利。
